PIMS is to provide a current status report in respect of physical parts (generally pipes) of the pipeline. Items included in addition to pipes are bends, valves, assemblies, joints and tees.
During the lifetime of the GAIL pipelines, PIMS will keep track of the information related to the constituent parts of the GAIL pipelines (Pipes, Bends, Valves, Assemblies, Joints, Tees, Reducers) readily accessible.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
All information in PIMS will be kept as historical records, will act as a valuable tool to many areas of the Project in terms of future requirements, expectations and achieved performance.
Business Objective
Project Name : Dhamra Haldia Pipeline Project
| Project Name | : | Dhamra Haldia Pipeline Project | |
| Project Length | : | 253 Km. (Approx.) | |
| Material Specification | : | APL 5L GR. X70 PSL 2 | |
| Diameter | : | 18” | |
| Wall Thickness (mm) | : | 8.1 / 9.7 / 11.8 | |
| Coating | : | 3 LPE (External) & Epoxy (Internal) | |
| Client | : | GAIL INDIA LIMITED | |
| Consultant | : | ENGINEERS INDIA LTD. |  |
| Contractor | : | CORRTECH INTERNATIONAL PVT. LTD. |  |
| PIMS | : | Unistal Systems Pvt. Ltd. |  |
| Start Date | : | 23-Jul-2021 | |
| End Date | : | 22-Nov-2022 |
| Spread | Section | Chainage From | Chainage To | Length |
|---|---|---|---|---|
| Spread-1 | Section-1 | 0 KM | 89.000 KM | 89.000 KM |
| Spread-2 | Section-2 | 89.000 KM | 164.000KM | 75.00 KM |
| Spread-3 | Section-3 | 164.000KM | 252.954 KM | 88.954 KM |
�
Services By Unistal System Pvt. Ltd.
